Bromic Tungsten Smart-Heat Electric
Electric Patio Heater
From $958
MSRP. Prices can change; see the current price online or in the showroom.
Bromic's Tungsten Smart-Heat Electric combines an industrial design with directional radiant heat. A thick steel coil in fused quartz and a parabolic reflector behind a honeycomb fascia focus infrared warmth where it is needed. 3000W, 4000W and 6000W, in black or white, 208V, 240V or 277V. Mounting brackets for wall or ceiling included; pair it with a Bromic Affinity control.
Highlights
- 3000W / 4000W / 6000W
- 208V, 240V & 277V
- Black or White (4000W & 6000W)
- Smart-Heat technology
Features
- Thick steel coil inside translucent fused-quartz element for high-output radiant heat
- Parabolic specular reflector (PSR) directs infrared energy efficiently
- Honeycomb fascia for precise, even heat distribution
- Superior wind resistance compared with convection heaters
- Adjustable brackets for directional heating; wall, ceiling, pole or recessed mount
- Dual-element 4000W/6000W models allow staged output
- Compatible with Affinity Smart-Heat on/off, dimmer and home-automation controls
Specifications
| Model | BH0420031 |
| Wattage | 3000W single element; 4000W and 6000W dual element |
| Voltage | 240V (3000W, 4000W, 6000W); 208V and 277V (4000W, 6000W) |
| Rated current | 208V: 19.23A (4kW), 28.85A (6kW) · 240V: 12.5A (3kW), 16.6A (4kW), 25A (6kW) · 277V: 14.44A (4kW), 21.66A (6kW) |
| Dimensions | 44 in long (4000W); 56 in long (3000W, 6000W) |
| Colors | Black (all); White (4000W and 6000W) |
| Mounting options | Wall, ceiling, pole (tube suspension) or recessed/flush; 6.5 in adjustable brackets included |
| Clearances | Min. floor clearance 72 in wall-mount / 96 in ceiling-mount; 3 ft side clearance to combustibles |
| IP rating | IPX4 |
| Certification | Intertek ETL / cETL 4005951 (site lists CSA Approved) |
| Finish | Matte black or white on stainless steel |
| Controls included | No - on/off, dimmer or home-automation control purchased separately |
Options
- 3000W 56 in Black 240V ($958)
- 4000W 44 in Black 240V ($991)
- 4000W 44 in White 240V ($1,023)
- 6000W 56 in Black 240V ($1,161)
- 6000W 56 in White 240V ($1,182)
- 4000W 44 in Black 208V ($1,055)
- 4000W 44 in White 208V ($1,075)
- 6000W 56 in Black 208V ($1,214)
- 6000W 56 in White 208V ($1,246)
- 4000W 44 in Black 277V ($1,055)
- 4000W 44 in White 277V ($1,075)
- 6000W 56 in Black 277V ($1,214)
- 6000W 56 in White 277V ($1,246)
Compatible accessories
- Affinity Smart-Heat On/Off Control
- Affinity Smart-Heat Dimmer Control
- Affinity Smart-Heat Ethernet Expansion Board
- Affinity Manual Indoor Single 20A Switch 120-277V
- Affinity Manual Indoor Dual 20A Switch 120-277V
- Affinity Manual Outdoor Single 20A Switch 120-277V
- Affinity Manual Outdoor Dual 20A Switch 120-277V
- Tungsten Electric Ceiling Recess Kit - 4000W
- Tungsten Electric Ceiling Recess Kit - 3000W & 6000W
- Tungsten Electric Suspension Kit
- Tungsten Electric Short Mounting Bracket Set
- Tungsten Electric Long Mounting Bracket Set
- Retrofit Kit for Tungsten Electric Heaters
- PHS Rain & Sun Heater Cover - 56 in (3000W/6000W)
